Pump series FP4100
FP4100 - FP4100+ - FP4104
| max. flow | 10 m³/h |
| max. head | 12 m |
| max. motor power | 0.55kW |
| Phases | Single-Phase Tri-Phase |
Pump series FP4100 - FP4100+ - FP4104
The FP4100 pump series is our original milk pump and is still a reference in this segment after many years of use.
Its simple construction with an adjusted impeller makes the FP4100 series an extremely high-performance pump for use in dairy farming.
Its simple construction with an adjusted impeller makes the FP4100 series an extremely high-performance pump for use in dairy farming.
Application areas
The milk pumps of the FP4100 series are mainly used in the smaller conventional milking machines for cows, sheep or goats and in milk transfer systems. In addition to pumping the milk, these pumps are also extremely suitable for use in the cleaning cycles of these installations.
Your benefits
- High pump efficiency resulting in lower energy consumption
- Good air handling
- Electropolished, easy to clean
- Simple construction and easy to maintain
- Compact installation dimensions
- Best "Value for money"
Technical information
| Specifications | |
| max. flow rate | 10 m³/h |
| max. differential head | 12 m |
| max. motor power | 0.55 kW |
| max. speed | 3000/3600 rpm |
| available frequency | 50/60 Hz |
| All stainless steel parts | ASI304 - Electropolished |
| Food contact compliant | 1935/2004 EC |
| FP4100+ compliant to | 3-A Sanitary Standards |
FP4100
FP4104
